Automatic Copper Wire Feeding Winding Machine

The robotic interface is user-friendly and easy to learn. Simply input the product resistance value and the copper wire feeding position, and the machine will automatically adjust to produce qualified products. Each segment's resistance is precise, and the positioning and length of the automatically fed copper wire are accurate, ensuring a high level of automation. It is suitable for heating wires with segmented copper wire feeding (such as defrosting lines for refrigerators) and heating wires with different segmented resistances.

Online detection of resistance (ohm value)
simultaneous feeding of multiple copper wires
segmented different resistances
automatic shutdown upon reaching specified length
automatic broken wire detection
alarms for no wire feeding, cut-off wire, or misaligned copper wire position.

Parameter List
Resistance Wire Diameter Range	Ф0.03-0.20mm
Wire Spool Diameter	within Ф100
Core Wire Pay-off and Winding Shaft Diameter	Standard Ф350	(Note: Customizable according to customer requirements)
Power Supply	220V, 50/60HZ
Motor Power	400W, 370W, 100W
Maximum Speed	Up to 4000rpm	(Note: speed is dependent on the diameter of the wire being wound)
Length Resistance Error	Within ±3%
Pitch Error	Within ±3%
